Parts Manual for EPSON XP-255 XP-257

In stock

SKU

EP-XP255-PM

$1.10

***** The following content is not included in the PDF manual *****

***** Please refer to the details ONLINE ******

Article	Reference	Description

1789030	100	HOUSING,RIGHT ASSY.,CF32,METCO,ASP
1568270	101	HOUSING,LEFT
1577162	102	COVER,REAR,ICON
1789040	103	PANEL ASSY,CH17,A,METCO,ASP
1789015	105	PAPER SUPPORT ASSY.,CC05,METCO,ASP
1610790	107	STAND,SC,B
1576993	108	TORSION SPRING,25.37
2190487	200	BOARD ASSY.,MAIN
2140467	204	CR CONTACT MODULE
2139742	205	CONNECTOR,CSIC
2179218	300	POWER SUPPLY UNIT
2192160	350	WIRELESS LAN USB MODULE
1548493	501	LEVER,DETECTORPE
2158910	505	BOARD ASSY.,ENCORDER,PF,B
1646107	506	POROUS PAD,PAPER GUIDE,LOWER,D
1789017	507	HOLDER RETURD ASSY.,CC05,METCO,ASP
1789019	508	FRAME PUMP ASSY,,CC03,METCO,ASP
1789020	510	SHAFT ROLLER LD ASSY.,CC05,METCO,ASP
1593349	511	SCALE,CR
1789021	513	CAP ASSY.,CC86,METCO,ASP
1789023	514	PAPER GUIDE FRONT ASSY.,CE56,METCO,ASP
2175802	515	MOTOR,ASSY.,CR
1789025	517	CR ASSY.,F2,B,,CF32,METCO,ASP
2150122	518	CABLE,HEAD,F2,35
2149815	519	CABLE,CSIC,F2
2150124	519	CABLE,CSIC,F2
1548518	521	SCALE,PF
2145562	525	CABLE,PIS
2150454	526	BOARD ASSY.,SUB
1548528	527	CLUTCH
1548529	528	SPUR GEAR,37.2
1548530	529	EXTENSION SPRING,0.137
1548494	531	EXTENSION SPRING,0.067
1548561	533	LEVER,LOCK,SLIDER
FA04040	700	Ersetzt durch: FA04060
1567191	701	HOLDER,BOARD
1789027	703	TRAY POROUSPAD,ASSY.,CD91,METCO,ASP
1569226	705	LABEL,INK POSITION
1595846	706	COVER,CABLE,HEAD,F2
1789034	800	SCANNER UNIT.,CF32,METCO,ASP
1789037	801	COVER DOCUMENT ASSY.,CF32,METCO,ASP
