EPSON XP-3100 XP-3105 XP-3150 XP-3155 EW-452A Parts Manual

In stock
SKU
EP-XP3100-PM
$1.20
  • Email with download link immediately
  • Files without viruses
  • PDF format manual
  • Allow high-definition printing
Links
$1.20
More Information
Manual Name EPSON XP-3100 XP-3105 XP-3150 XP-3155 EW-452A Parts Manual
Format PDF
PDF Archive 1.75M
Pages 4
Brand EPSON
Type SERVICE or PARTS MANUAL
Compatible Model Epson XP-3100 Series




****** The following content is not included in the PDF manual, please use it online ******

Article Reference Description
1764221 100 HOUSING,LEFT,21W
1796928 101 COVER,INK EJECT,ASSY ASP
1764210 102 HOUSIING,RIGHT
1764222 103 HOUSING,UPPER,REAR
1764213 104 COVER,FFC
1796927 106 HOPPER ASSY,CG30,IEI,ASP
1768658 108 STACKER ASSY,CG30,IEI
1796918 111 PANEL ASSY,CG32 NON EHC,IEI,ASP
1850575 111 PANEL ASSY,CG32 NON EHC,IEI,ASP
1284698 112 H.N.-1,3,F/ZN-3C
1764263 113 STAND,SC,SUPPORT
2194955 200 BOARD ASSY.MAIN
2193662 300 BOADR ASSY.,POWER SUPPLY
2194159 350 WIRELESS LAN USB MODULE
2207229 350 WIRELESS LAN USB MODULE
1796926 501 INK SYSTEM ASSY,CG30,IEI,ASP
1768660 502 ROLLER LD ASSY,CG30,IEI
1855206 502 ROLLER LD ASSY,CG30,IEI
1807240 504 PAPER GUIDE,UPPER,CENTER,ASSY,B,ASP
1807245 505 PAPER GUIDE,UPPER,RIGHT,ASSY,B,ASP
1807243 506 PAPER GUIDE,UPPER,LEFT,ASSY,B,ASP
2189475 507 MOTOR,ASSY,CR
1796921 508 CARRIAGE F2 ASSY.,ASP
1796930 510 CABLE,HEAD ASSY,ASP
2181521 511 BOARD ASSY.,SNS
1548528 512 CLUTCH
1801341 513 HOLDER,CLUTCH
1718063 514 EXTENSION SPRING,0.137
1796932 515 MOTOR,PF ASSY,CG30,IEI,ASP
1801344 521 SPUR GEAR,CLUTCH,45.6
1859312 521 SPUR GEAR,CLUTCH,45.6
1796937 531 HOLDER STARWHEEL, ASSY,CG30,IEI.,ASP
2196627 533 CABLE,PIS
1796933 542 ROLLER,PF ASSY,CG30,IEI.,ASP
FA04040 700 Ersetzt durch: FA04060
1796913 702 DUPLEX ASSY,CG30,IEI,ASP
1764246 704 PIN,POROUS PAD
1764271 705 POROUS PAD,PAPER GUIDE,FRONT
1746669 711 SCALE,CR,180
2181518 712 BOARD ASSY.,ENCODER
1581304 713 SCALE PF ASSY,CG30,IEI
1548480 714 EXTENSION SPRING,1.41
1768685 715 HOLDER RETARD ASSY,CG30,IEI
1718074 718 EXTENSION SPRING,0.023
1796920 719 LEVER, AP SENSOR,ASSY,ASP
2197079 720 PHOTO INTERRUPTER,ASF
1764232 721 COVER,CABLE,HEAD
1768687 722 HOLDER BOARD ASSY ,CG30,IEI
1693877 723 HOLDER,CONNECTOR,CSIC,IS
1796939 724 GROUNDING PLATE,HEAD,F2 ASSY,ASP
1764231 725 GUIDE,FFC
2197925 726 CONECTOR,CSIC
2196561 727 CABLE,CSIC,INK EJECT
1760358 729 POROUS PAD,CR,F2
2190470 730 CABLE,ENCODER,PF,B
1796911 800 SCANNER UNIT,CG32,NON EHC,IEI, ASP
1866438 800 SCANNER UNIT,CG32,NON EHC,IEI, ASP
1881706 800 SCANNER UNIT,CG32,NON EHC,IEI, ASP
1801136 801 COVER,DOCUMENT,SC,IEI,ASP
1764348 802 COVER,ASF
1694135 803 MAT,COVER,DOCUMENT
