Parts Manual for EPSON StylusPhoto R220 R230
In stock
SKU
EP-R230-PM
$1.20
- Email with download link immediately
- Files without viruses
- PDF format manual
- Allow high-definition printing
***** The following content is not included in the PDF manual *****
***** Please refer to the details ONLINE ******
| Model | Article | Reference | Description |
| STYLUS PHOTO R220/230 | 1429662 | 1 | SHEET CDR ASSY.,E |
| STYLUS PHOTO R220/230 | 1413157 | 100 | COVER,PRINTER,ASSY,R220 |
| STYLUS PHOTO R220/230 | 1296660 | 101 | HOUSING,FRAME,C,EDG |
| STYLUS PHOTO R220/230 | 1268974 | 102 | PAPER SUPPORT ASSY.,C546,ASP |
| STYLUS PHOTO R220/230 | 1413155 | 103 | HOUSING LEFT ASSY.,C626,B |
| STYLUS PHOTO R220/230 | 1412101 | 104 | HOUSING,RIGHT,EDG2 |
| STYLUS PHOTO R220/230 | 1268966 | 105 | STACKER ASSY.,C546,ASP |
| STYLUS PHOTO R220/230 | 1296655 | 106 | PANEL,BUTTON,C,ENM3 |
| STYLUS PHOTO R220/230 | 1412109 | 107 | BUTTON,SW,B,EDG2 |
| STYLUS PHOTO R220/230 | 1278830 | 108 | GUIDE,BUTTON,SW |
| STYLUS PHOTO R220/230 | 1273377 | 109 | LABEL,CAUTION |
| STYLUS PHOTO R220/230 | 1274134 | 110 | LABEL,CAUTION,CD-R |
| STYLUS PHOTO R220/230 | 1269877 | 111 | COVER,INK TUBE,EDG |
| STYLUS PHOTO R220/230 | 1273572 | 112 | STOPPER,PAPER STACKER,B |
| STYLUS PHOTO R220/230 | 2107328 | 200 | BOARD ASSY.,MAIN |
| STYLUS PHOTO R220/230 | 5975E,C626 ASP | ||
| STYLUS PHOTO R220/230 | 1431030 | 300 | Replace: 1443461 |
| STYLUS PHOTO R220/230 | 1443461 | 300 | POWER SUPPLY ASSY.,C546,ASP,B |
| STYLUS PHOTO R220/230 | 2083795 | 310 | BOARD ASSY.,INTERFACE |
| 6000A,STANDARD | |||
| STYLUS PHOTO R220/230 | 2084482 | 320 | HARNESS |
| STYLUS PHOTO R220/230 | 2083793 | 450 | BOARD ASSY.,PANEL |
| STYLUS PHOTO R220/230 | 6001A,STANDARD | ||
| STYLUS PHOTO R220/230 | 2084443 | 460 | CABLE,PANEL |
| STYLUS PHOTO R220/230 | 2105934 | 500 | Replace: 2116002 |
| STYLUS PHOTO R220/230 | 2116002 | 500 | Replace: 2121119 |
| STYLUS PHOTO R220/230 | 2121119 | 500 | PRINTER MECHANISM(ASP) |
| STYLUS PHOTO R220/230 | 1261530 | 501 | CARRIAGE |
| STYLUS PHOTO R220/230 | 1261542 | 504 | HOLDER,FFC |
| STYLUS PHOTO R220/230 | 1269923 | 505 | HOLDER,FFC,B |
| STYLUS PHOTO R220/230 | 2090735 | 506 | BOARD ASSY.,DETECTOR,PW |
| STYLUS PHOTO R220/230 | 1249464 | 507 | CAP,DETECTOR,PW |
| STYLUS PHOTO R220/230 | 1269561 | 508 | GUIDE,IC |
| STYLUS PHOTO R220/230 | 1282407 | 509 | C.B.P-TITE SCREW,2.5X8,F/ZN-3C |
| STYLUS PHOTO R220/230 | 1261531 | 510 | HOLDER,I/C |
| STYLUS PHOTO R220/230 | 2082722 | 511 | HARNESS,PW |
| STYLUS PHOTO R220/230 | 2086286 | 512 | BOARD ASSY.,ENCORDER |
| STYLUS PHOTO R220/230 | 1299381 | 513 | TIMING BELT,E |
| STYLUS PHOTO R220/230 | 1269562 | 514 | LEVER,CARTRIDGE |
| STYLUS PHOTO R220/230 | 2084306 | 515 | CABLE,HEAD |
| STYLUS PHOTO R220/230 | 1261545 | 516 | SHAFT,CR,GUIDE |
| STYLUS PHOTO R220/230 | 1261564 | 519 | EXTENSION SPRING,3.289 |
| STYLUS PHOTO R220/230 | 1081759 | 520 | SCALE,CR |
| STYLUS PHOTO R220/230 | 1410935 | 521 | APG ASSY.,C626 |
| STYLUS PHOTO R220/230 | 1414607 | 523 | PAPER GUIDE UPPER SET ASSY. |
| STYLUS PHOTO R220/230 | 2084519 | 525 | MOTOR ASSY.,CR |
| STYLUS PHOTO R220/230 | 2103883 | 525 | MOTOR ASSY.,CR |
| STYLUS PHOTO R220/230 | 1263327 | 526 | FIXED SPRING,CR SHAFT,RIGHT |
| STYLUS PHOTO R220/230 | 1295131 | 527 | BUSHING,PARALLEL ADJUST,RIGHT,B |
| STYLUS PHOTO R220/230 | 1270223 | 528 | EXTENSION SPRING,PUSH UP PLATE,R |
| STYLUS PHOTO R220/230 | 1263326 | 529 | FIXED SPRING,CR SHAFT,LEFT |
| STYLUS PHOTO R220/230 | 1295135 | 530 | BUSHING,PARALLEL ADJUST,LEFT,B |
| STYLUS PHOTO R220/230 | 1269003 | 531 | PAPER GUIDE FRONT ASSY.,ASP |
| STYLUS PHOTO R220/230 | 1401122 | 532 | POROUS PAD,PAPER GUIDE,FRONT,B |
| STYLUS PHOTO R220/230 | 1292581 | 533 | POROUS PAD,PAPER GUIDE,FRONT,SUPPORT,B |
| STYLUS PHOTO R220/230 | 1401493 | 534 | POROUS PAD,PAPER GUIDE,FRONT,LEFT,B |
| STYLUS PHOTO R220/230 | 1261592 | 535 | SPUR GEAR,41.38 |
| STYLUS PHOTO R220/230 | 1270224 | 536 | EXTENSION SPRING,PUSH UP PLATE,L |
| STYLUS PHOTO R220/230 | 1263380 | 537 | COMPRESSION SPRING,1.27 |
| STYLUS PHOTO R220/230 | 2089355 | 538 | MOTOR ASSY.,PF,B |
| STYLUS PHOTO R220/230 | 1268957 | 539 | FRAME EJ,ASSY.,ASP |
| STYLUS PHOTO R220/230 | 1298231 | 540 | ROLLER EJ ASSY. |
| STYLUS PHOTO R220/230 | 1405037 | 541 | CDR,GUIDE,FRAME ASSY.,H,C546,ASP |
| STYLUS PHOTO R220/230 | 1043083 | 542 | COMPRESSION SPRING,5.1 |
| STYLUS PHOTO R220/230 | 1040649 | 543 | LOCK,STACKER |
| STYLUS PHOTO R220/230 | 2084414 | 544 | SENSOR ASSY.,CDR |
| STYLUS PHOTO R220/230 | 1283268 | 545 | Replace: 1437858 |
| STYLUS PHOTO R220/230 | 1437858 | 545 | INK SYSTEM ASSY.,B |
| STYLUS PHOTO R220/230 | 1262113 | 546 | LEVER,LOCK,SLIDER |
| STYLUS PHOTO R220/230 | 1244305 | 547 | COMBINATION GEAR,27.2,19.2 |
| STYLUS PHOTO R220/230 | 1261630 | 548 | LEVER,CHANGE |
| STYLUS PHOTO R220/230 | 1250632 | 549 | COMPRESSION SPRING,2.36 |
| STYLUS PHOTO R220/230 | 1250989 | 550 | SPUR GEAR,25.6 |
| STYLUS PHOTO R220/230 | 1244304 | 551 | SPUR GEAR,27.2 |
| STYLUS PHOTO R220/230 | 1261596 | 552 | COMBINATION GEAR,20.82,24 |
| STYLUS PHOTO R220/230 | 1270339 | 554 | SHIELD PLATE,FFC |
| STYLUS PHOTO R220/230 | 2082758 | 555 | BOARD ASSY.,CSIC |
| STYLUS PHOTO R220/230 | 2060802 | 556 | CONNECTER,CSIC |
| STYLUS PHOTO R220/230 | 1261590 | 557 | ROLLER,PF |
| STYLUS PHOTO R220/230 | 1303728 | 558 | CARRIAGE ASSY.,ASP SDOTT-PARTS |
| STYLUS PHOTO R220/230 | 1275672 | 559 | TORSION SPRING,LEVER,CARTRIDGE |
| STYLUS PHOTO R220/230 | 1263395 | 561 | BUSHING,ROLLER,PF,LEFT |
| STYLUS PHOTO R220/230 | 1261578 | 562 | BUSHING,ROLLER,PF,RIGHT |
| STYLUS PHOTO R220/230 | F166000 | 700 | PRINT HEAD |
| 540 | |||
| STYLUS PHOTO R220/230 | 1423420 | 701 | ASF ASSY.,I |
| STYLUS PHOTO R220/230 | 1268943 | 702 | ROLLER,RETARD,ASSY.,ASP |
| STYLUS PHOTO R220/230 | 1262190 | 703 | COMPRESSION SPRING,2.51 |
| STYLUS PHOTO R220/230 | 1295626 | 704 | POROUS PAD,INK EJECT,SMALL,B |
| STYLUS PHOTO R220/230 | 1295625 | 705 | POROUS PAD,INK EJECT,UPPER,B |
| STYLUS PHOTO R220/230 | 1295624 | 706 | POROUS PAD,INK EJECT,LOWER,B |
| STYLUS PHOTO R220/230 | 1262455 | 707 | Replace: 1482604 |
| STYLUS PHOTO R220/230 | 1482604 | 707 | POROUS PAD,CAP,LOWER,LARGE |
| STYLUS PHOTO R220/230 | 1272087 | 708 | Replace: 1482606 |
| STYLUS PHOTO R220/230 | 1482606 | 708 | POROUS PAD,CAP,LOWER,SMALL |
| STYLUS PHOTO R220/230 | 1300403 | 709 | POROUS PAD,INK EJECT,UPPER,SUPPORT,B |
| STYLUS PHOTO R220/230 | 1249453 | 710 | POROUS PAD,SLIDER,CAP,D6 |
| STYLUS PHOTO R220/230 | 1244284 | 711 | INSULATOR,FRAME,MAIN |
| STYLUS PHOTO R220/230 | 1217084 | 712 | FOOT |
| STYLUS PHOTO R220/230 | 1279180 | 713 | Replace: 1436387 |
| STYLUS PHOTO R220/230 | 1436387 | 713 | HOLDER SHAFT ASSY.,B,ASP |
| STYLUS PHOTO R220/230 | 1075955 | 714 | ROLLER,LD,B SDOTT.COM |
| STYLUS PHOTO R220/230 | 1218235 | NON FIG | GREASE G-63 |
| 40 GRAM |
| Manual Name | StylusPhoto R220 R230 Parts Manual |
|---|---|
| Format | |
| PDF Archive | 1.4M |
| Pages | 9 |
| Type | SERVICE or PARTS MANUAL |
| Compatible Model | EPSON StylusPhoto R220 R230 Series |
